INDRIVE® Like the Hollow Shaft Drives the

Solid Shaft Drives can be  configured in either the direct drive or the right angle drive configurations.  Below are the Models and specifications for each unit.

INDRIVE® Solid Shaft Drives Feature:




* Low Cost Economical Design - designed for the

  most cost effective applications



* Lift Off Belt Guard -  for  easy access and adjustments.



* Small Unobtrusive Size - low profile, light weight, easy to

    handle.



* Axial Load Ratings - to fit any application



* Field Proven Reliability



*Heavy Duty and Durable

            INDRIVE® SOLID SHAFT DRIVES

                 SD & SR SERIES

SD15X 13,700 15
SR15X 13,700 7.5 Yes
SD15S 13,700 30
SR15S 13,700 15 Yes
SD15M 13,700 75
SR15M 13,700 40 Yes
SD25S 28,000 30
SR25S 28,000 15 Yes
SD25M 28,000 75
SR25M 28,000 40 Yes
SD30M 28,000 75
SR30M 28,000 40 Yes

SD30L

28,000 >75
SR30L 28,000 >40 Yes
SD40M 37,000 75
SR40M 37,000 40 Yes
SD40L 37,000 >75
SR40L 37,000 >40 Yes
SD50M 52,500 75
SR50M 52,500 40 Yes
SD50L 52,500 >75
SR50L 52,500 >40 Yes

        Note: The last letter in the model name indicates the torque capacity

        of the backspin brake: X= 400 ft-lb; S = 640 ft-lb; M = 2000 ft-lb; and

        L = 8000 ft-lb.

        ** Gas Engine Drive Systems Usually Incorporate A Pillow Block

        Assembly

        +Actual Hp Rating Is Dependent On The Speed And Torque Of The

         Application
