| (H) = Hollow Shaft | (D) = Direct Drive |
(15) = 13,700 Lb Axial Rating |
(X) = 400Ft-Lb |
(LC) = Load Cell PCPOS® |
MAX. Rating If Not Supplied |
|||
| (S) = Solid Shaft |
(R) = Right Angle Drive |
(25) = 28,000 Lb Axial Rating |
(S) = 640 Ft-Lb |
(xxxx) On "R" Drives Is The Gearbox Model |
Actual Size if Supplied |
|||
| (DC) = Direct Coupled |
(30) = 28,000 Lb Axial Rating |
(M) = 2,000 Ft-Lb |
(BLANK) = No Additional Features |
GED-GAS Engine Drive |
||||
|
(40) = 37,000 Lb Axial Rating |
(L) = 8,000 Ft-Lb | |||||||
|
(50) = 52,500 Lb Axial Rating |
(H) = Hydraulic-No Brake |
|||||||
|
EXAMPLE: SDC30MLC-50 |
||||||||
| (S) Solid Shaft | (DC) Direct Coupled |
(30) 28,000 Lb Axial Rating |
(M) 2,000 Ft-Lb Brake |
(LC) Load Cell PCPOS® |
50 HP Rating | |||
